Internal Hard Drives

P300

Performance that meets demands

Toshiba’s P300 3.5” internal hard drive delivers a high performance for professionals. With its dual-stage actuator, you can count on smooth, responsive computing. What’s more, your data and media is secured with a ramp loading design, as well as a shock sensor. The P300 is available in capacities up to 3 TB.

Use for:
• Powerful desktop workstations
• All-in-one PCs
• Desktop PCs
• External enclosures
• Gaming computers

  • 3.5" SATA Hard Drive
  • 7200 rpm
  • 64 MB buffer
  • Advanced Format
  • Perfect for: Challenging applications including gaming, photo editing and video review
3 TB 2 TB 1 TB 500 GB
Color
Powerful storage
The P300 is ideal for graphic designers and creative professionals looking for a powerful performance. Available in storage capacities of up to 3 TB, with fast read and write speeds and a secure design.

Performance alongside reliability

The P300’s dual-stage actuator, available in the 2 TB and 3 TB models, improves positional accuracy, negating the effects on head-track alignment that vibrations can cause. This design makes for more precise, faster read and write speeds, and instant access to your data.

Advanced read and write technology

With Perpendicular Magnetic Recording technology (which can deliver more than three times the storage density of traditional recording, and accounts for the P300’s high capacity) and Tunnel Magneto-Resistive Recording technology (for improved stability) the P300 is equipped for fast and secure reading and writing of data.

Keep data secure

The P300’s design includes an internal shock sensor, ensuring no data is lost. In addition, ramp loading technology means that when your hard drive or desktop PC are being transported, the drive slider does not make contact with the disk and risk wearing or data loss.

Innovating worldwide

Toshiba is renowned the world over for 50 years of leading innovation – the power behind its range of hard drives is no exception. Designed for high capacity and excellent performance, you can be sure that Toshiba’s wealth of experience in hard drives is at work in your desktop PC.

Product Specifications

  • Acoustics (idle mode)
    27 dB typ. (3 TB & 2 TB), 25 dB typ. (1 TB & 500 GB)
  • Acoustics (seek mode)
    28 dB typ. (3 TB & 2 TB), 26 dB typ. (1 TB & 500 GB)
  • Advanced Format (AF)
    Yes
  • Average latency
    4.17 ms
  • Box Content

    • 3.5-inch internal HDD - P300 High-Performance Hard Drive
    • Quick Start Guide
    • Warranty leaflet

  • Buffer size
    64 MB
  • Consumption – Low Power Idle
    5.2 W typ. (3 TB & 2 TB), 3.7 W typ. (1 TB & 500 GB)
  • Consumption – Read/Write
    6.4 W typ.
  • Dimensions

    147 (L) x 101.6 (W) x 26.1 (H) mm

  • Form factor

    3.5-inch

  • Halogen Free
    Yes
  • Interface
    SATA 6.0 Gbit/s
  • Native Command Queing (NCQ)
    supported
  • RoHS compatible
    Yes
  • Rotational speed
    7,200 rpm
  • S.M.A.R.T Support
    No
  • Shock (non-operating)

    3,430 m/s2 {350 G} (2 ms half sine) (500 GB & 1 TB)
    2,920 m/s2 {350 G} (2 ms half sine) (2 TB & 3 TB)

  • Shock (operating)

    686 m/s2 {70 G} (2 ms half sine)

  • Supply voltage
    5VDC (±5%) / 12VDC (±10%)
  • Temperature (operating / non-operating)
    0 to 60° C / -40 to 70 °C
  • Unrecoverable error rate
    1 per 10E14 bits read
  • Vibration (non-operating)
    10.2 m/s2 {1.04 G} (2 to 200 Hz)
  • Vibration (operating)

    6.57 m/s2 {0.67 G} (5 to 500 Hz)

  • Weight (approx.)

    680 g max. (3 TB & 2 TB)
    450 g max. (1 TB & 500 GB)

Product Range

Part number Capacity Color
HDWD130EZSTA (Retail) 3 TB -
HDWD130UZSVA (Bulk) 3 TB -
HDWD120EZSTA (Retail) 2 TB -
HDWD120UZSVA (Bulk) 2 TB -
HDWD110EZSTA (Retail) 1 TB -
HDWD110UZSVA (Bulk) 1 TB -
HDWD105EZSTA (Retail) 500 GB -
HDWD105UZSVA (Bulk) 500 GB -
