Internal Hard Drives

V300

Stream. Record. Edit.

Toshiba’s 3.5-inch V300 Video Streaming Hard Drive with up to 3 TB lets you stream, record, edit and play video content on DVR, TV or NVR – with all the efficiency and reliability you need. A 64 MB buffer helps deliver smooth performance, while temperature control technology limits heat buildup, extending service life for added reliability. A drive that’s quiet and more efficient than ever, thanks to Toshiba’s Silent Seek Technology, and reduced energy consumption.

Use for:
• Video Editing Systems
• Set-Top-Box (STB)
• Digital Video Recorders (DVR)
• Network Video Recorders (NVR)
• Video Surveillance Systems

  • 3.5" SATA Hard Drive
  • 64 MB buffer
  • 24/7 operation
  • Toshiba Silent Seek Technology
  • Temperature control
3 TB 2 TB 1 TB 500 GB
Colour
Capacity at your service
The V300 is available in a range of storage capacities to meet your specific requirements, with up to 3 TB. This series of 3.5-inch internal HDDs all come with a 64 MB internal data buffer, to ensure your video experience never slows down. And with an industry-standard SATA interface providing up to 6 GBit/s transfer, the action never stops!

Streaming performance you can depend on

Designed for the reliable delivery of multiple and simultaneous high resolution streams, the V300 takes video content delivery to another level. A 64 MB buffer helps to deliver smooth performance while longer service-life reliability through curbed heat generation helps prevent overheating.

Optimised for the viewer's experience

The speed and performance of the V300 is delivered with a whisper, thanks to Toshiba's Silent Seek Technology to minimize noise and heat during operation. The low acoustics of the hard drive are optimized for the simlutaneous recording and streaming offered by today's DVRs and STBs. With quality like this, nothing gets in the way of a great viewing and listening experience.

Keeping cool when the action heats up

The efficient low spin design of the V300 helps to lower the energy consumption for video recording, editing and streaming features by up to 25% (compared to the P300, 7200 rpm model). With an extended temperature range, the hard drive is optimized for today's standard video recorders and set-top boxes, even when placed in high-temperature environments.

Built to deliver, designed to last

Toshiba is renowned the world over for 50 years of leading innovation – and the power behind its range of hard drives is no exception. Designed for high capacity and excellent performance, you can be sure that Toshiba’s wealth of experience in hard drives is at work in your storage system.

Product Specifications

  • Basic Specifications
  • Form factor

    3.5-inch

  • Interface

    6.0 Gbit/s

  • Number of cameras supported

    up to 8

  • Drive bays supported

    4

  • Advanced Format (AF)

    Yes

  • RoHS compatible

    Yes

  • Halogen Free
    Yes
  • Shock Sensor

    Yes

  • Performance
  • Rotational speed

    5940 rpm (3 TB),
    5700 rpm (500 GB - 2 TB)

  • Buffer size

    64 MB

  • Native Command Queing (NCQ)
    Supported
  • Reliability
  • Workloads
    72 TB/year
  • Unrecoverable error rate

    1 per 10E14 bits read

  • 24/7 operation

    Yes

  • Load / Unload Cycle

    300.000

  • Power Management
  • Supply voltage

    5V DC ±5%; 12V DC ±10%

  • Consumption – Read/Write

    5.40 W typ. (3 TB),
    4.70 W typ. (2 TB),
    5.70 W typ. (500 GB, 1 TB)

  • Consumption – Low Power Idle

    4.20 W typ. (3 TB),
    3.30 W typ. (2 TB),
    3.00 W typ. (500 GB, 1 TB)

  • Environmental
  • Temperature (operating / non-operating)

    0 - 65° C / -40 - 70° C

  • Vibration (operating)

    0.67 G (5 to 500 Hz)

  • Vibration (non-operating)

    1.04 G (2 to 200Hz)

  • Shock (operating)

    70 G / 2 ms duration

  • Shock (non-operating)

    300 G / 2 ms half sine

  • Acoustics (idle mode)

    24 dB typ. (3 TB),
    22 dB typ. (2 TB),
    19 dB typ. (500 GB - 1 TB)

  • Physical
  • Dimensions

    147 (L) x 101.85 (W) x 26.1 (H) mm

  • Weight (approx.)

    680 g max. (2 TB, 3 TB),
    450 g max. (500 GB, 1 TB)

  • Box Content
  • Box Content

    3.5-inch internal HDD - V300 Video Streaming Hard Drive

Product Range

Part number Capacity Color
HDWU130UZS5A (Bulk) 3 TB -
HDWU120UZS5A (Bulk) 2 TB -
HDWU110UZS5A (Bulk) 1 TB -
HDWU105UZS5A (Bulk) 500 GB -

Where to buy

All features depending on model and local availability. The complete disclaimer and legal information can be found here: disclaimer
